  • Adaptor, N Male(Plug) to N Female(Jack) Right Angled

Adaptor, N Male(Plug) to N Female(Jack) Right Angled

item code : B44-A2103-01
  • Fast production and delivery
  • The High Quality and cost effective products
  • Various adapter types are available for supply
Specification Product Inquiry
  • Product information
    Electrical Specification
    Item Specification
    Frequency Range DC ~ 11 GHz
    Connector Type N Male(Plug) to N Female(Jack)
    V.S.W.R. 1.20 : 1 / Max
    Impedance 50 Ω
    Mating 500
    RoHS Compliance
    Working voltage 1000V rms
    Coupling nut proof torque 22kg -cm
    Coupling nut retention force 50 kg.f
    Material specification
    Item Specification
    Center Contact (Pin) Be-Cu / Gold plated
    Body Brass / Nickel plated
    Insulator PTFE
  • Drawing
  • Description

    General Information

    RF Coaxial Adaptor is a device that converts specification of a coaxial connector to other coaxial connector. Through this RF coaxial adaptor, the electrical signals from a connector can be transmitted to other type of connector.


    Feature

    – Various type of Adaptor is available.

    – No Minimum Order Quantity.

    – RoHS Compliant.

    – Welcome to a Customized product.
